WIRING WS1000W Occ Sensor, Pir, 120V 500W

Product Description

The WIRING DEVICE-KELLEMS WS1000W is an occupancy sensor that controls lighting in residential and commercial environments. This device employs passive infrared (PIR) technology to detect movement, ensuring efficient lighting based on occupancy. Operating at 120V AC with a power rating of 500W, it is ideal for single-circuit applications. The WS1000W allows for both automatic and manual lighting control options.

• Utilizes passive infrared (PIR) technology for occupancy detection.
• Designed for coverage areas of 1000 to 1200 square feet.
• Adjustable time delay settings between 20 seconds and 30 minutes.

Product Highlights

Product Information

Standard Information

• Brand: WIRING
• MPN: WS1000W

Technical Specifications

• Voltage Rating: 120 VAC
• Power Rating: 500 W
• Sensor Type: Passive Infrared
• Coverage: 1000-1200 sq. ft
• Time Delay: 20 s to 30 min
• Control Output: Automatic/Manual On
• Color: White
• Dimensions: 1.82 inches W x 0.61 inches D x 4.15 inches H
• Operating Temperature: 32 to 122 degrees F
• Connection Type: Wire Lead
• Mounting Type: Threaded
