White Rodgers 50F06-843 Universal Furnace Electronic Timer 115-230 Vac

Product Description

The White Rodgers 50F06-843 is a universal furnace electronic timer. This device is designed for use with non-integrated single-stage furnaces. It enhances efficiency by controlling the operation of the furnace fan. The timer has features that support both PSC inducer and blower motors.

• Works with non-integrated furnace controls
• Includes six mounting hole options
• Transformer connections with terminal options

Product Highlights

This electronic timer helps to automate furnace fan operation, ensuring optimal airflow and temperature management within the system.

Product Information

Standard Information

• Brand: White Rodgers
• MPN: 50F06-843

Technical Specifications

• Voltage Rating: 24VAC Input, 115 - 230VAC Line
• Ampere Rating: 800mA Input
• Frequency Rating: 60 Hz
• Operating Temperature Range: -40 to 175 deg F
• Length: 7 inch
• Width: 5 inch
• Depth: 1-1/2 inch
• Humidity: 5 - 95% Relative
• Applications: For Non-Integrated Single Stage Furnace
