Whirlpool w10757851 Ice Maker Emitter Control Board

Product Description

The WHIRLPOOL w10757851 is an ice maker emitter receiver control board designed for use in refrigerators where ice cubes dump directly into an ice bin located in the freezer door. This board uses an infrared light beam to signal the ice maker to cycle on and off based on the ice level in the bin. When the beam is blocked by ice, the ice maker stops production. When the beam is clear, production resumes. Licensed refrigeration technicians and qualified appliance service pros install this component as a direct OEM-style replacement during ice maker diagnostic and repair calls.

This control board is intended for side-by-side and French door refrigerator configurations where the ice storage bin sits in the freezer door rather than inside the freezer compartment. The emitter and receiver work as a paired optical system. Failure of this board typically presents as the ice maker running continuously, failing to produce ice, or overfilling the bin. It replaces part numbers 4389102, AP3137510, AP5956767, PS557945, and PS10064583.

Key Features

• Infrared beam technology signals ice maker on and off based on bin fill level
• Designed for freezer-door ice bin configurations
• Direct replacement for multiple superseded and cross-reference part numbers
• OEM-style fit for Whirlpool, KitchenAid, and Kenmore manufactured refrigerators

Compatibility

Designed as an OEM-style replacement for Whirlpool, KitchenAid, and Kenmore manufactured refrigerators equipped with a freezer-door ice bin. Replaces part numbers 4389102, AP3137510, AP5956767, PS557945, and PS10064583.

Installation Notes

Installation should be performed by a qualified appliance technician. Disconnect power to the refrigerator at the outlet or circuit breaker before removing any panels or handling the control board. Allow the freezer compartment to reach a safe working temperature before servicing the ice maker assembly. Confirm the replacement board is properly seated and all wire harness connectors are fully engaged before restoring power.

Technical Specifications

• Function: Ice maker emitter receiver optical control
• Application: Freezer-door ice bin refrigerators

Standard Information

• Brand: WHIRLPOOL
• Manufacturer Part Number: w10757851
