Westinghouse 904532 Air Handler Control Board

Product Description

The WESTINGHOUSE 904532 is a replacement control board designed for multi-poise indoor air handler systems. This board manages the operating logic of the air handler, coordinating blower motor sequencing, communication with the thermostat or system controller, and overall unit function. It is a direct OEM-style replacement intended for installation by licensed HVAC technicians. The 904532 is built to restore proper air handler operation in systems where the original control board has failed or been damaged.

This control board is specified for use in multi-poise indoor air handler configurations, meaning the unit can be installed in multiple orientations to suit the installation layout. It is suited for residential or light-commercial applications where the PAH2VM-series or iQDrive-series air handlers are deployed. Typical installs involve replacement during a no-heat, no-cool, or communication fault diagnosis on the affected air handler.

Key Features

• Direct replacement control board for PAH2VM-series multi-poise indoor air handlers
• Compatible with iQDrive system platforms
• Supports multi-poise installation orientations
• Manages blower sequencing and system communication functions
• OEM-specified part number for accurate fitment

Compatibility

Designed for use with the PAH2VM-E36KB and PAH2VM-E48KC multi-poise indoor air handlers operating under the PAH2VM and iQDrive platforms.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect all power to the air handler at the breaker before removing the existing control board or handling any wiring. Follow the existing wiring layout carefully before disconnecting leads, and refer to the unit wiring diagram located on the equipment cabinet. Observe all applicable local codes and manufacturer guidelines during replacement.

Technical Specifications

• Item Type: Control Board
• Application: Multi-Poise Indoor Air Handler
• Compatible Model Series: PAH2VM, iQDrive
• Compatible Part Numbers: PAH2VM-E36KB, PAH2VM-E48KC

Standard Information

• Brand: WESTINGHOUSE
• Manufacturer Part Number: 904532
