Westinghouse 903962 Inducer Venter Motor with Gasket

Product Description

The WESTINGHOUSE 903962 is an inducer venter motor kit with gasket designed for residential condensing furnace applications. This blower kit provides the combustion air induction necessary to draw flue gases through the heat exchanger and exhaust them safely out of the structure. Rated at 1/15 HP with a 2-pole, single-stage motor and counterclockwise (CCW) rotation, it delivers consistent draft performance suited to the tight tolerances of condensing furnace venting systems. The included gasket ensures a proper sealed connection at the inducer housing, reducing the risk of flue gas leakage at the mounting interface.

This inducer blower kit is intended for residential condensing furnaces. It is used on 040-08, 040-12, 080-16, and 092-VB model residential condensing furnace units. The kit is typically installed by licensed HVAC technicians during routine maintenance, component failure replacement, or system refurbishment on affected furnace models.

Key Features

• Rated at 1/15 HP for consistent combustion air induction performance
• 2-pole, single-stage motor configuration
• Counterclockwise (CCW) rotation matches OEM inducer assembly orientation
• Includes mounting gasket for a sealed flue connection at the inducer housing
• Designed as a direct-fit replacement kit for specified residential condensing furnace models

Compatibility

Designed for use on 040-08, 040-12, 080-16, and 092-VB residential condensing furnace units as specified by the manufacturer.

Installation Notes

Installation should be performed by a licensed HVAC technician. Before servicing, disconnect all electrical power to the furnace and allow the heat exchanger to cool completely. Verify rotation direction (CCW) prior to final connection to ensure proper draft performance. Follow all applicable local mechanical and fuel gas codes, including IFGC guidelines, when servicing furnace venting components.

Technical Specifications

• Horsepower: 1/15 HP
• Motor Poles: 2
• Stages: Single Stage
• Rotation: Counterclockwise (CCW)
• Kit Contents: Inducer venter motor and gasket
• Application: Residential condensing furnace

Standard Information

• Brand: WESTINGHOUSE
• Manufacturer Part Number: 903962
