Wesco EZ25DO 2-gang Plastic Cut-in Box

Product Description

The WESCO EZ25DO is a 2-gang plastic cut-in electrical box designed for retrofit and new-work installations in finished walls and ceilings. This box mounts without access to the back side of the wall cavity, making it the standard choice when opening a wall is not practical. Electricians use cut-in boxes when adding receptacles, switches, or low-voltage device plates to existing drywall or plaster surfaces. The plastic construction keeps the unit lightweight and non-conductive, which suits residential and light commercial wiring applications.

This box is suited for residential and light commercial electrical work where a 2-gang device opening is required in an already-finished wall. Typical applications include adding duplex receptacles, decorator switches, or combination device plates without tearing out drywall. The cut-in design uses integrated mounting ears or wings that clamp against the inside face of the wall material once the box is inserted through a field-cut opening.

Key Features

• 2-gang configuration accommodates side-by-side devices in a single opening
• Plastic construction — lightweight, non-conductive, and corrosion-resistant
• Cut-in design installs without access to the back of the wall cavity
• Compact footprint at 4 inches long by 3.1 inches wide for tight retrofit spaces

Compatibility

Designed as an OEM-style replacement and standard retrofit box for residential and light commercial 2-gang electrical device installations in drywall or plaster walls.

Installation Notes

Installation is performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the circuit at the breaker panel and verify with a non-contact voltage tester before cutting the wall opening or pulling wires. Use the box itself or a supplied template to mark the cut-in opening, and ensure the wall material thickness is within the clamp range of the mounting ears before seating the box.

Technical Specifications

• Gang Count: 2-gang
• Material: Plastic
• Length: 4 inches
• Width: 3.1 inches
• Box Type: Cut-in (old-work)

Standard Information

• Brand: WESCO
• Manufacturer Part Number: EZ25DO
