Watson Mcdaniel UTD450SM Thermodynamic Trap Module

Product Description

Watson McDaniel UTD450SM is a thermodynamic steam trap module for drip and tracing applications, designed to drain condensate from steam mains and other steam supply lines. The module mounts to any 2-bolt Quick-Change Universal Connector and fastens with two bolts, allowing removal and replacement in minutes without disconnecting piping. Constructed of stainless steel with a hardened seat, it is suitable for vertical or horizontal installations and handles up to 450 psig.

• Mounts to any 2-bolt Quick-Change Universal Connector; fastened with two bolts for quick replacement without disconnecting piping
• All stainless steel construction with hardened seat
• Maximum operating pressure 450 psig and maximum capacity 2.5 lb/hr at 450 psig; compatible with UC450, UC450SR, UC450SBR connectors

Product Highlights

Thermodynamic steam trap module for drip and tracing; quick-change 2-bolt mounting; 450 psig, 2.5 lb/hr capacity

Product Information

Standard Information

• Brand: WATSON MCDANIEL
• Manufacturer Part Number: UTD450SM
