Victaulic L024007GO0 Zero-Flex 7 Series Pipe Rigid Coupling with Gasket

Product Description

The Victaulic Zero-Flex L024007GO0 is a pipe rigid coupling designed to ensure a secure connection in piping systems. This coupling is crafted from ductile iron and features a hot dipped galvanized finish for durability. The unique angled pad design fosters a strong grip that adjusts to standard pipe tolerances, effectively resisting flexural and torsional loads.

• Designed for nominal size 2-1/2 inches
• Compatible with grooved pipe connections
• Rated for a maximum pressure of 750 psi

Product Highlights

This coupling is suitable for standard wall carbon steel pipe, rolled or cut grooved as per Victaulic specifications.

Product Information

Standard Information

• Manufacturer: Victaulic
• Brand: Victaulic

Technical Specifications

• Dimensions: 2.875 inches OD x 1.84 inches W
• End Style: Grooved
• Finish: Hot Dipped Galvanized
• Fitting/Connector Type: Coupling
• Length: 6.38 inches
• Material: Ductile Iron
• Nominal Size: 2-1/2 inches
• Pressure Rating: 750 psi
• Series: 7 Series
