Field Controls SWH-4 Vent Cap 4 Inch Aluminum

Product Description

This Field Controls SWH-4 Vent Cap is made of durable aluminum for use with 4-inch vent ducts. It is designed to provide clearance between the flue gas stream and wall combustibles, suitable for various applications including natural gas, LP gas, and oil-fired equipment. This cap is compliant with ANSI, NFPA211, and NFPA54 standards.

• Designed for 4-inch duct size
• Made from aluminum steel
• Includes backing plate

Product Highlights

This vent cap ensures safe and effective venting of gases, making it ideal for HVAC installations. It features a concentric pipe design with angled outlet deflectors and spaced plate design for improved performance.

Product Information

Standard Information

• Brand: Field Controls
• MPN: SWH-4
• Product Type: Vent Cap

Technical Specifications

• Material: Aluminum Steel
• Cap Height: 12 5/8 inches
• Cap Width: 10 5/8 inches
• Inlet Diameter: 6 inches
• Overall Length: 14 7/8 inches
• Inside Diameter: 3 inches
• Material Thickness: 19 ga
• Finish: Aluminum
