Venstar acc0401 Wired Indoor Temperature Sensor

Product Description

The VENSTAR acc0401 is a wired indoor temperature sensor designed to provide accurate ambient readings for compatible VENSTAR thermostat systems. The sensor operates across a wide temperature range of -40 to 125 degrees F, making it suitable for demanding residential and light commercial HVAC applications. Its compact housing measures 1.4 inches wide, 0.63 inches deep, and 1.8 inches tall, allowing straightforward installation in tight spaces. Licensed HVAC technicians and skilled installers typically deploy this sensor as a remote sensing point, enabling thermostats to monitor temperatures in zones away from the main thermostat location.

This sensor is intended for indoor use and is compatible with VENSTAR thermostats in both indoor and outdoor thermostat applications. It is used with specific VENSTAR thermostat models including T1100FS, T1700, T1800, T1900, T2700, T2800, T2900, T2300FS, and TSTATEZ units. It is well suited for residential HVAC zoning setups or commercial installations where remote temperature monitoring is required to improve system efficiency and comfort control.

Key Features

• Wide operating range of -40 to 125 degrees F for demanding environments
• Compact form factor at 1.4 inches wide, 0.63 inches deep, and 1.8 inches tall
• Wired connection provides reliable, consistent signal to the thermostat
• Supports remote zone sensing for improved temperature accuracy
• Compatible with multiple VENSTAR thermostat platforms including T1700, T1800, T1900 series and TSTATEZ

Compatibility

Designed for use with VENSTAR thermostats T1100FS, T1700, T1800, T1900, T2700, T2800, T2900, T2300FS, and TSTATEZ. Verify thermostat firmware and wiring terminal availability before installation.

Installation Notes

Installation should be performed by a licensed HVAC technician familiar with low-voltage thermostat wiring. Power down the thermostat system at the air handler or furnace disconnect before connecting or disconnecting the sensor. Route sensor wiring away from high-voltage conductors to avoid signal interference. Consult the thermostat installation manual for sensor terminal assignments and configuration steps.

Technical Specifications

• Operating Temperature Range: -40 to 125 degrees F
• Width: 1.4 inches
• Depth: 0.63 inches
• Height: 1.8 inches
• Application: Indoor and Outdoor Thermostat
• Connection Type: Wired

Standard Information

• Brand: VENSTAR
• Manufacturer Part Number: acc0401
