Uniweld TYPE11-6 Heating Tip, Oxy-Acetylene, Rosebud, MFA, 6

Product Description

The UNIWELD TYPE11-6 heating tip is designed for preheating and straightening. Compatible with acetylene fuel, this rosebud style tip fits torch series 300 and HD 310C. It features a tube and head design and is compatible with Victor torches. The MFA series tip has a size of 6 and produces a large heat zone flame.

• Designed for Preheating & Straightening
• Made in USA
• Fits Journeyman series 1 series handles

Product Highlights

This heating tip is compatible with WH360, WH360L, 72L9, and 72L11 welding handles and supports a maximum fuel flow rate of 40 scfh.

Product Information

Standard Information

• Brand: UNIWELD
• Manufacturer Part Number: TYPE11-6
• Country of Origin: United States

Technical Specifications

• Item: Heating Tip
• Size: 6
• Type: Rosebud
• Series: MFA
• Includes: One Complete Tip
• Tip Size: 6
• Flame Type: Large Heat Zone, Preheating, Straightening
• Tip Design: Tube & Head
• Gas Service: Acetylene
• Oxygen Flow: 15 to 44
• For Use With: 72L11, 72L9, Uniweld Handle WH360, WH360L
• Acetylene Flow: 14 to 40 scfh
• Oxygen Pressure: 10 to 15 psi
• Acetylene Pressure: 8 to 12 psi
• Compatible Fuel Type: Acetylene
• Maximum Fuel Flow Rate: 40 scfh
• Minimum Fuel Flow Rate: 14 scfh
• Compatible Manufacturer: Victor
• Compatible Torch Series: 300, HD 310C
• Maximum Oxygen Flow Rate: 44 scfh
• Minimum Oxygen Flow Rate: 15 scfh
• Fuel Type (per Tip Series): Acetylene
• Minimum Fuel Pressure Rating: 7 psig (Acetylene)
• Minimum Oxygen Pressure Rating: 10 psig
• Pressure Rating (Fuel, Maximum): 10 psig (Acetylene)
• Pressure Rating (Oxygen, Maximum): 15 psig
• Compatible Torch Manufacturer Part Number: 315FC, 72L11, 72L9, H 315FC, HD 310C, WH360, WH360L
• Vendor: Uniweld
• Application: Preheating, Straightening
