Uniweld MR8211 Regulator Acetylene CGA510

Product Description

The UNIWELD MR8211 is a single-stage regulator designed for acetylene with a CGA510 connection. It features a T-handle for smooth flow adjustment and a machined brass body and bonnet. The regulator has a neoprene diaphragm and a porous bronze inlet filter. It controls pressure from high-pressure cylinders for oxy-fuel applications.

• Equipped with a machined brass body and bonnet.
• Features an easy-to-read single scale 2" gauge.
• Includes a 1-5/8" tri-layered reinforced neoprene diaphragm.

Product Highlights

This medium-duty regulator ensures precise pressure control for cutting, heating, and welding with acetylene, offering durability and ease of use.

Product Information

Standard Information

• Brand: UNIWELD
• Manufacturer Part Number: MR8211
• Country of Origin: United States

Technical Specifications

• Number of Stages: Single Stage
• Compatible Gas Type: Acetylene
• Control Type: T-Handle
• Manufacturer Part Number: MR8211
• Inlet Connection Gender: Female
• Outlet Pressure (Maximum): 15 psig
• Outlet Connection Gender: Male
• Outlet Connection Size: 9/16"-18
• Body Material: Brass
• Diaphragm Material: Neoprene
• CGA Number: CGA 510
• Hose Fitting Size: B
• Bonnet Material: Brass
• Duty Rating: Medium/Standard Duty
• Overall Depth: 4.5 in
• Overall Width: 7 in
• Gauge Diameter: 2 in
• Overall Height: 5.5 in
• Filter Material: Bronze
• Regulator Series: MR82
• Outlet Connection: 9/16"-18 M LH
• Outlet Thread Direction: Left Hand
• Inlet Pressure (Maximum): 3,000 psig
• Outlet Pressure (Minimum): 2 psig
• Inlet Connection: CGA 510
• Inlet Thread Direction: Left Hand
• Application: Low Pressure
• Standards: UL 592H
• Max Inlet Pressure: 3,000 psig
• Outlet Pressure: 2 psig
