TRERICE D82LFB2502LA030 Industrial Vacuum Pressure Gauge

Product Description

The TRERICE D82LFB2502LA030 is a vacuum pressure gauge that meets high performance standards. It features a two-and-a-half inch dial that measures pressure from thirty inches of mercury vacuum to thirty PSI. The gauge includes a quarter inch MNPT lower connection and an aluminum dial with clear markings for easy reading.

• Two-and-a-half inch dial size.
• Pressure range: thirty inches Hg vacuum to thirty PSI.
• Quarter inch MNPT lower connection.

Product Highlights

This gauge is suitable for various industrial applications that require precise measurement of vacuum and pressure levels.

Product Information

Standard Information

• Manufacturer: Trerice
• Item Code: D82LFB2502LA030

Technical Specifications

• Series/Model: Model D82LB
• Dial Size: Two-and-a-half inches
• Measuring Range: Thirty inches Hg - thirty PSI
• Connection: Quarter inch MNPT Lower
• Accuracy: Plus/minus 1.6% Full Scale
• Case Material: 304 Stainless Steel
• Tube Material: Bronze
• Filled With: Glycerin
• Mounting: Stem
• Temperature Rating: 150 degrees Fahrenheit
• Industry Standards: ASME B40.100, CRN Approved
• Diameter: 2.68 inches
