Trerice 800B4002LA140 Utility Pressure Gauge 0 - 300 psi

Product Description

The Trerice 800B4002LA140 is a utility pressure gauge designed for general pressure indication. It features a durable black drawn steel lower mount. The gauge has a four inch dial and measures pressure from zero to three hundred psi.

• Designed for general pressure indication needs
• Reliable service with economical cost
• Wetted parts include bronze tube and lead-free brass socket

Product Highlights

This pressure gauge is suitable for various applications and is certified for safety and performance.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H O Trerice

Technical Specifications

• Accuracy: Plus/Minus 1.6% Full Scale
• Connection Size: 1/4 in
• Connection Type: MNPT
• Depth: 1.38 in
• Dial Size: 4 in
• Diameter: 3.94 in
• Finish: Black
• Item Name: Pressure Gauge
• Material: Drawn Steel
• Measuring Range: 0 - 300 psi
• Model: 800B
• Mounting: Lower
• Temperature Rating: 180 deg F
• Type: Utility
• Standards/Certifications: ANSI/NSF 61 and 372 certified, cULus MH59892 listed, ASME B40.100
