Trerice 800B2502LA130 Pressure Gauge Utility 0 - 200 psi

Product Description

The Trerice 800B2502LA130 is a utility pressure gauge designed for general pressure indication requirements. This gauge features a black drawn steel flangeless case and provides precise pressure readings from zero to two hundred psi. It is suitable for a variety of applications.

• Accuracy of plus/minus 1.6% full scale
• Constructed with a bronze tube and lead-free brass socket
• Temperature rating of 180 degrees Fahrenheit

Product Highlights

The gauge features a clear acrylic window and is easy to install with a lower mounting style. It meets ANSI/NSF standards and is certified for safe use in various environments.

Product Information

Standard Information

• Brand: Trerice
• Model: 800B

Technical Specifications

• Accuracy: Plus/Minus 1.6% Full Scale
• Connection Size: 1/4 in
• Connection Type: MNPT
• Depth: 1.16 in
• Dial Size: 2-1/2 in
• Diameter: 2.48 in
• Finish: Black
• Material: Drawn Steel
• Measuring Range: 0 - 200 psi
• Mounting: Lower
• Temperature Rating: 180 degrees F
• Type: Utility
