Trerice 800B2502LA080 Pressure Gauge Utility 0 - 15 psi Replacement MPN

Product Description

The Trerice 800B2502LA080 is a utility pressure gauge that accurately indicates pressure levels. This pressure gauge is designed for various applications, providing essential data where pressure measurements are required. The gauge has a two and one-half inch dial and reads from zero to fifteen psi.

• Durable design with bronze tube and lead-free brass socket.
• Sturdy drawn steel, black finished casing.
• Meets ANSI/NSF 61 and 372 standards for safety.

Product Highlights

This gauge is suitable for a variety of industrial and commercial applications, ensuring reliable service.

Product Information

Standard Information

• Brand: Trerice
• Manufacturer: H O Trerice

Technical Specifications

• Model: 800B
• Type: Utility
• Connection Size: 1/4 in
• Connection Type: MNPT
• Accuracy: Plus/Minus 1.6% Full Scale
• Dial Size: 2-1/2 in
• Diameter: 2.48 in
• Depth: 1.16 in
• Material: Drawn Steel
• Finish: Black
• Measuring Range: 0 - 15 psi
• Temperature Rating: 180 deg F
• Mounting: Lower
• Standards/Certifications: ANSI/NSF 61 and 372 certified, cULus MH59892 listed, ASME B40.100
• Applications: For a variety of general applications
