Product Description
The Tekmar 152 is a two-stage setpoint control designed for precise temperature management in various HVAC applications. This versatile control operates either as a two-stage setpoint control or as two independent setpoint controls, providing flexibility for diverse heating and cooling needs.
- Microprocessor-based control
- Supports both heating and cooling applications
- Features user-friendly interface
Product Highlights
Enhance your HVAC systems with the Tekmar 152 Two Stage Setpoint Control. Ideal for industrial environments, this control offers reliable performance and durability. It is easy to set up and operate, ensuring optimal temperature management through sequential operations based on predefined setpoints.
Product Information
Standard Information
-
Brand: Tekmar
-
Model: 152
-
Category: SetPoint Controls
Technical Specifications
-
Dimensions: 4-3/4 H x 2-7/8 W x 7/8 D
-
Weight: 0.8 lbs (0.845 actual)
-
Voltage: 24V AC / DC
-
Power Supply: Class 2, 24 V (ac) +10% 50/60 Hz 2 VA or 32 V (dc) +20% 0.04 A
-
Relays: 240 V (ac) 10 A, 1/3 hp, pilot duty 240 VA
-
Sensors Included: NTC thermistor, 10 kΩ @ 77°F (25°C +0.2°C)
-
Control Accuracy: +0.5°F (+0.3°C) with up to 500 feet of 18 AWG wire to sensors
-
Temperature Range: -40 to 239°F (-40 to 115°C)
-
Ambient Conditions: Indoor use only, -20 to 120°F (-30 to 50°C), < 90% RH non-condensing
-
Approvals: CSA C US, meets ICES & FCC regulations for EMI/RFI
