Spears S1520C07F 3/4 PVC Clear Utility Swing Check Valve Thread EPDM

Product Description

Spears S1520C07F is a 3/4 inch PVC clear utility swing check valve. This valve features FNPT end style and supports pressure ratings of 150/75 psi. It is designed for handling water media and is constructed from chemical and corrosion-resistant PVC material.

• Maintenance-free sealed unit with a compact design
• Suitable for horizontal and vertical installations
• Long life EPDM seat with weighted disc

Product Highlights

This utility swing check valve is engineered for maximum flow and quick response. It offers a reliable shut-off for various applications.

Product Information

Standard Information

• Brand: Spears
• Part Number: S1520C07F

Technical Specifications

• Body Material: PVC
• Color: Clear
• Dimensions: 2-1/8 inches H
• End Style: FNPT
• Inlet to Outlet Length: 4-1/16 inches
• Media: Water
• Nominal Size: 3/4 inch
• Pressure Rating: 150/75 psi
• Temperature Rating: 140 degrees F
• Trim Material: EPDM
• Domestic/Import: Domestic
