Southwire Coleman Cable 50001TV 24hr Mechanical Timer 15A

Product Description

The SOUTHWIRE/COLEMAN CABLE 50001TV is a heavy-duty indoor mechanical timer designed for daily 24-hour plug-in control of grounded electrical loads. It accepts a standard 3-prong grounded plug and provides one grounded 3-prong outlet for the controlled device. Rated at 125 volts, 15 amps, and 1,250 watts for tungsten loads at 60 Hz, it is built for reliable repetitive switching in residential and light commercial settings. A manual override switch allows the outlet to be toggled independently of the programmed schedule, giving installers and end users direct control when needed.

This timer is suited for indoor use in applications where daily on/off scheduling is required, such as lighting circuits, seasonal displays, fans, pumps, and similar plug-in loads. Electricians and facilities technicians commonly deploy units like this for energy management on non-critical circuits. It is CFL-ready, making it compatible with compact fluorescent lamp loads. Programming is set in 30-minute intervals, allowing up to 48 individual on/off events per 24-hour cycle.

Key Features

• Daily 24-hour mechanical programming in 30-minute intervals
• Maximum 48 individual on/off settings per day
• Manual override on/off switch for direct load control
• Single grounded 3-prong outlet output
• CFL-ready for compact fluorescent lamp compatibility
• CSA Certified for safety compliance

Compatibility

Designed as a plug-in replacement timer for grounded 3-prong indoor electrical devices rated up to 15 amps and 125 volts, including tungsten lamp loads up to 1,250 watts and CFL fixtures.

Installation Notes

Installation is performed by plugging the timer into a standard 15-amp grounded indoor outlet and connecting the controlled device to the timer outlet. No hardwiring is required. Verify that the connected load does not exceed the rated amperage and wattage before energizing. Consult NEC guidelines for appropriate circuit loading when multiple devices share a branch circuit.
