Southwire 630tbs Top Bite Saddle Connector 3/8 Inch

Product Description

The SOUTHWIRE 630tbs is a 3/8 inch top bite saddle connector designed for securing conduit or cable runs to structural surfaces. The saddle design allows the connector to clamp firmly around the conduit from the top, providing a stable mechanical hold without requiring access to the back of the surface. This type of fitting is a standard component in electrical rough-in work and is typically installed by licensed electricians during conduit installation in both new construction and retrofit applications.

The 630tbs is suited for use in residential and light commercial electrical installations where 3/8 inch conduit or flexible conduit needs to be secured to framing, joists, or other structural members. The top bite design simplifies single-side installation in tight or confined spaces where conventional saddle connectors may be difficult to position.

Key Features

• 3/8 inch nominal size for compatibility with standard 3/8 inch conduit
• Top bite clamping mechanism allows single-side installation
• Saddle connector style provides secure mechanical retention of conduit
• Compact form factor suited for confined framing cavities and tight runs

Compatibility

Designed as an OEM-style replacement or standard-fit saddle connector for 3/8 inch conduit installations in residential and light commercial electrical systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements for conduit support and securing intervals. De-energize all circuits in the work area before beginning conduit work. Use appropriate fasteners rated for the mounting surface to ensure the saddle connector holds securely under load.

Technical Specifications

• Conduit Size: 3/8 inches
• Connector Type: Top Bite Saddle

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 630tbs
