Southwire 55213142 Low Voltage Cable 16/2 50 Ft

Product Description

The SOUTHWIRE 55213142 is a 50-foot, 16/2 stranded low voltage cable rated for applications up to 150 volts. It features two 16-gauge stranded conductors wrapped in a black PVC (polyvinyl chloride) insulated jacket. The conductors are duplexed in a flat construction, which allows the cable to be split apart quickly during termination and installation. Licensed electricians and landscape lighting installers use this cable for outdoor low-voltage wiring runs where a clean, manageable conductor layout is required. The operating temperature range runs from -20 degrees C to 60 degrees C, making it suitable for most North American climate conditions year-round.

This cable is designed for outdoor accent lighting, landscape lighting, and security lighting systems that do not exceed 150 volts. It can be installed underground or left exposed to direct sunlight without degradation of the jacket material. Typical applications include connecting low-voltage path lights, spotlights, and step lights to a transformer in residential or light commercial landscape installations. The 50-foot length suits most standard residential yard runs without requiring a splice.

Key Features

• 16-gauge, 2-conductor stranded construction for flexibility during installation
• Flat duplex design allows easy conductor teardown without tools
• Black PVC jacket rated for direct sunlight exposure and underground burial
• Rated for systems up to 150 volts
• Operating temperature range: -20 degrees C to 60 degrees C
• 50-foot spool length suitable for standard residential landscape runs

Compatibility

Designed as an OEM-style replacement or standard supply cable for residential and light commercial low-voltage landscape and security lighting systems rated at 150 volts or less.

Installation Notes

Installation is typically performed by a licensed electrician or qualified landscape lighting technician. De-energize the low-voltage transformer completely before making any conductor connections. When burying the cable, follow local code requirements for burial depth, which are generally referenced under NEC Article 411 for low-voltage lighting systems. Avoid sharp bends or pinch points that could damage the PVC jacket and compromise insulation integrity.

Technical Specifications

• Conductor Gauge: 16 AWG
• Number of Conductors: 2
• Conductor Type: Stranded
• Cable Length: 50 feet
• Maximum Voltage Rating: 150 volts
• Jacket Material: PVC (polyvinyl chloride)
• Jacket Color: Black
• Construction: Flat duplex
• Operating Temperature: -20 degrees C to 60 degrees C
• Weight: 1.868 pounds

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 55213142
