Southwire 52C3-UPC 4x4 Square Raised Cover Fixture Ring

Product Description

The SOUTHWIRE 52C3-UPC is a round fixture ring designed to mount light fixtures in walls and ceilings. It converts a 4-inch square electrical box to a 3-1/2-inch round opening, making it a practical solution for lighting retrofit work. The cover includes 8-32 threaded mounting tabs that accept standard fixture hardware. Angled slots built into the cover compensate for up to 1/2 inch of box misalignment on upright framing members, reducing rework during rough-in and finish stages. Licensed electricians and lighting contractors install this cover as part of residential and light commercial fixture installations. The 52C3-UPC carries UL listing and RoHS compliance.

This fixture ring is suited for residential and light commercial applications where a 4-inch square box needs to be transitioned to a round fixture opening. It is commonly used during lighting retrofits when replacing or upgrading ceiling or wall-mounted light fixtures. The on-center spacing of 2-3/4 inches aligns with standard fixture mounting patterns. The design accommodates minor box misalignment, which is especially useful when working with existing framing that may not be perfectly plumb.

Key Features

• Converts 4-inch square electrical box to a 3-1/2-inch round opening
• 8-32 threaded mounting tabs for standard fixture hardware compatibility
• Angled slots compensate for up to 1/2 inch of box misalignment
• 2-3/4-inch on-center mounting hole spacing
• UL listed and RoHS compliant

Compatibility

Designed as an OEM-style replacement cover for 4-inch x 4-inch square electrical boxes used in residential and light commercial fixture mounting applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). Power to the circuit must be shut off at the breaker before beginning any fixture or cover work. Confirm the 8-32 threaded tabs align with the fixture mounting ears before tightening. Do not over-tighten mounting screws, as this may damage the threaded tabs.

Technical Specifications

• Box Compatibility: 4 inches x 4 inches square
• Round Opening Diameter: 3-1/2 inches
• On-Center Mounting Spacing: 2-3/4 inches
• Box Misalignment Compensation: Up to 1/2 inch
• Mounting Tab Thread: 8-32
• Weight: 0.256 pounds
• Certifications: UL Listed, RoHS Compliant

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 52C3-UPC
