Southwire 43111004 Genesis 16 AWG 2-Conductor Solid Riser Fire Alarm Cable (1000 ft) 43111004

Product Description

Southwire 43111004 is a riser-rated, unshielded fire alarm cable with two solid 16 AWG bare copper conductors, polypropylene insulation and a PVC jacket. The cable is rated 300 V, temperature rated -20 C to 75 C, and supplied on a 1000 ft pull box. It features a rip cord and Countdown length markings and meets UL 1666, UL 1424 (FPLR), UL 13 (CL3R) and CSA C22.2 No. 2556 (FT4).

• Two solid 16 AWG bare copper conductors; unshielded with polypropylene insulation
• PVC jacket with rip cord and Countdown length markings; supplied on a 1000 ft pull box
• Electrical and environmental ratings: 300 V; -20 C to 75 C; UL 1666, UL 1424 (FPLR), UL 13 (CL3R), CSA C22.2 No. 2556 (FT4); sunlight resistant; REACH/RoHS compliant

Product Highlights

Riser-rated 16 AWG 2-conductor solid fire alarm cable, 300 V, -20 C to 75 C, polypropylene insulation, PVC jacket, rip cord, Countdown markings, 1000 ft.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 43111004

Technical Specifications

• Brand: Southwire
• Manufacturer Part Number: 43111004
• Product Family / Series: GEN18 (Genesis)
• Product Type: Fire alarm unshielded cable, riser
• Conductor Size: 16 AWG
• Number of Conductors: 2
• Stranding: Solid
• Conductor Material: Bare copper
• Shielding: Unshielded
• Insulation Material: Polypropylene
• Jacket Material: PVC
• Rated Voltage: 300 V
• Temperature Rating: -20 C to 75 C
• Length: 1000 ft
• Nominal Total Weight: 22 lbs per 1000 ft
• Nominal Outer Diameter: 0.165 in
• DC Resistance (Max): 4.1 ohms per 1000 ft at 20 C
• Capacitance (Nominal): 22.3 pF/ft
• Impedance (Nominal): 68 ohms
• Velocity of Propagation: 67%
• Packaging: 1000 ft pull box
• Rip Cord: Yes
• Standards & Approvals: UL 1666 (Riser), UL 1424 (FPLR), UL 13 (CL3R), CSA C22.2 No. 2556 (FT4)
• Sunlight Resistance: Sunlight resistant
• Compliance: REACH/RoHS compliant
