Southwire 411050503 Machine Tool Wire 10 Awg 500 Ft Orange

Product Description

The SOUTHWIRE 411050503 is a 10 AWG stranded machine tool wire rated for use in industrial control panels, automated machinery, and equipment wiring applications. The conductor features 105 strands of fine wire for flexible routing through tight cable trays and conduit runs. PVC insulation measures 0.18 inches in outside diameter and carries a maximum operating temperature of 221 degrees F, with a minimum operating temperature of -22 degrees F. This wire is suitable for licensed electricians and industrial maintenance technicians working on machine tool and control panel wiring to NEC and NFPA 79 requirements.

This wire is intended for use inside machine tools, industrial control enclosures, and automated equipment where flexibility and resistance to shop-floor contaminants are required. Its PVC jacket resists acids, moisture, and oils, making it appropriate for wet or chemically active environments typical of manufacturing facilities. The 500-foot spool length suits both large panel builds and production wiring runs. This wire meets NFPA 70 and NFPA 79 requirements for machine tool wiring and is listed under multiple UL standards.

Key Features

• 10 AWG stranded construction with 105 individual strands for increased flexibility
• PVC insulation rated from -22 degrees F to 221 degrees F operating temperature range
• Resistant to acids, moisture, and oils for demanding shop-floor environments
• 0.18-inch outside diameter for routing through standard conduit and cable trays
• Orange jacket color for circuit identification in control panel wiring
• Listed to UL 1063, UL 758, UL 83, and UL 1426; compliant with RoHS 2002/95/EC

Compatibility

Designed as a standard machine tool wire replacement or new-installation conductor for use in industrial control panels and automated equipment wiring applications meeting NFPA 79 and NFPA 70 code requirements.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NFPA 70 (NEC) and NFPA 79 for industrial machinery wiring. De-energize and lock out all circuits before pulling or terminating wire. Verify that conduit fill, conductor ampacity, and termination ratings are appropriate for the application before installation. Do not exceed the rated maximum operating temperature at the termination points or inside enclosures with elevated ambient heat.
