Southwire 32760312 multiconductor shielded cable, plenum 18 awg 5/c 250 ft

Product Description

The SOUTHWIRE 32760312 Multiconductor Shielded Cable is a plenum-rated cable designed for various installations, including fabricated ducts and environmental air spaces, as per NEC 300.22(B) and 300.22(C). This 18 AWG, 5-conductor cable features bare copper conductors for optimal conductivity and low voltage drop. It incorporates low-smoke PVC insulation, a foil shield, and a plenum PVC jacket. Rated for 300 Volts and temperatures from -20 °C to 75 °C, it includes a rip cord and Countdown® Length Markings for efficient use.

• Bare copper conductors ensure excellent conductivity and minimal voltage drop.
• Features low-smoke PVC insulation and a plenum PVC jacket for safety and compliance.
• Includes a foil shield over all conductors and a durable rip cord for easy stripping.

Product Highlights

Plenum-rated, shielded multiconductor cable with bare copper conductors, low-smoke PVC insulation, and Countdown® Length Markings.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 32760312

Technical Specifications

• Outer Jacket Color: NATURAL
• Conductor Color: WHITE/RED/GREEN/BROWN/BLACK
• AWG Size: 18 AWG
• Number of Conductors: 5
• Stranding: Stranded
• Shielding Type: Shielded
• Nominal Weight (lbs/1000ft): 38
• Nominal Weight (kg/km): 56
• Voltage Rating: 300 Volts
• Temperature Rating: -20 °C to 75 °C
• NFPA 262 Compliance: Plenum Rated
• CSA C22.2 No. 2556 Compliance: FT6 Rated
• UL 444 Compliance: Communication Cables, Type CMP (22 AWG - 16 AWG)
• UL 1424 Compliance: Cables for Power-Limited Fire-Alarm Circuits, Type FPLP
• UL 13 Compliance: Power-Limited Circuit Cables, Type CL3P
• Environmental Compliance: REACH/RoHS Compliant
