Southwire 22145009 18 AWG 2-Conductor Shielded Riser Cable (500 ft) GEN44

Product Description

Southwire 22145009 is an 18 AWG, 2-conductor stranded shielded riser cable for low-voltage and life-safety installations. It uses stranded bare copper conductors with polypropylene insulation, an overall foil shield (with drain wire), and a PVC jacket on a 500 ft reel. The cable is rated 300 Volts and for operating temperatures from -20 degrees C to 75 degrees C, with rip cord and Countdown length markings for jacket removal and tracking.

• Two stranded 18 AWG bare copper conductors with polypropylene insulation
• Overall foil shield with drain wire and PVC jacket; riser rated (CMR/FT4) for vertical runs
• Rated 300 Volts; operating temperature -20 degrees C to 75 degrees C; 500 ft length

Product Highlights

Riser-rated 18 AWG shielded cable with polypropylene insulation, PVC jacket, foil overall shield, and 500 ft reel length

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 22145009

Technical Specifications

• Brand: Southwire
• Manufacturer Part Number: 22145009
• Product Code: GEN44
• Product Type: Multiconductor shielded cable, riser
• Gauge: 18 AWG
• Number of Conductors: 2
• Stranding: Stranded
• Conductor Material: Bare copper
• Conductor Insulation: Polypropylene
• Shielding: Overall foil shield with drain wire
• Drain Wire: Included
• Jacket Material: PVC
• Jacket Color: Gray
• Jacket Rating: Riser (CMR); FT4
• Length: 500 ft
• Voltage Rating: 300 Volts
• Operating Temperature: -20 °C to 75 °C
• Nominal Total Weight: 18 lbs per 1000 ft (approx.)
• Standards and Certifications: UL 1666 (Riser Rated); CSA C22.2 No. 2556 (FT4 Rated); UL 444 (Communication Cables); CL3R (where applicable); REACH/RoHS Compliant
• Typical Applications: Security, control, audio, fire alarm, low-voltage and life-safety systems
• Additional Features: Durable rip cord; Countdown length markings
