Southwire 1126 Conduit End Bell 2 Inch Pvc

Product Description

The SOUTHWIRE 1126 is a PVC conduit end bell designed to provide a smooth, flared entry point at conduit terminations, protecting wire and cable insulation from abrasion during pull-through. Measuring 2.812 inches in diameter and 1.5625 inches in height, this fitting is sized for 2-inch conduit installations. Electricians install this fitting at panel knockouts, junction boxes, and enclosure entries where conduit terminates and conductors must transition without risk of jacket damage. The PVC construction resists corrosion and is suitable for both indoor and outdoor applications.

This end bell is used in residential and commercial electrical conduit systems where a 2-inch conduit run terminates at an enclosure, pull box, or equipment entry point. It is a standard component in wire-pull setups, reducing friction and preventing insulation cuts at the conduit mouth. Typical installations include service entrances, panel feeders, and equipment branch circuits where large-gauge conductors are being pulled through conduit.

Key Features

• Flared bell mouth reduces abrasion on wire and cable insulation during pulls
• PVC construction provides corrosion resistance for indoor and outdoor use
• Sized for 2-inch conduit terminations
• Compact profile at 2.812 inches diameter and 1.5625 inches height
• Suitable for use at panel knockouts, junction boxes, and enclosure entries

Compatibility

Designed as an OEM-style fitting for use with 2-inch PVC conduit systems in standard residential and commercial electrical installations.

Installation Notes

Installation is performed by a licensed electrician. De-energize all circuits and follow lockout/tagout procedures before working at any enclosure or panel. Seat the end bell securely at the conduit termination point before pulling wire to ensure the bell mouth is properly aligned with the conduit bore. Installations must comply with applicable NEC requirements for conduit fittings and wiring methods.

Technical Specifications

• Size: 2 inches
• Diameter: 2.812 inches
• Height: 1.5625 inches
• Material: PVC
• Product Category: Conduit End Bells

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 1126
