Southwire 1-WBA Madison 3/4 Hangers W/Bolt

Product Description

The SOUTHWIRE 1-WBA Madison 3/4 Hangers W/Bolt are conduit hangers designed for supporting EMT/Rigid conduit. Constructed from 18 gauge steel with a bright zinc electroplated finish. These hangers are self-threading and do not require a nut. UL (Canada and US) Listed.

• Constructed from 18 Gauge Steel
• Features a Bright Zinc Electroplated Finish
• UL (Canada and US) Listed

Product Highlights

Conduit hangers with bolt for supporting EMT/Rigid conduit. Self-threading, nut not required.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 1-WBA

Technical Specifications

• Type: Conduit Hanger with Bolt
• Trade Size: 1 Inch
• Conduit Type: 3/4 Inch Rigid/EMT
• Material: 18 Gauge Steel
• Finish: Bright Zinc Electroplated
• Mounting Hole Size: 1/4 Inch
• Standard Package: 100
• Approval: UL (Canada and US)
• Screw Size: 1/4 Inch x 1 Inch
• Model #: 1-WBA
• UPC #: 784297150616
• Product Height: 1.684 inch
• Product Width: 1.684 inch
• California Prop 65: Yes
• EMT Size: 3/4"
• Rigid Size: 3/4"
• Suitable For Use With: EMT/Rigid Conduits
• Application: For secures EMT or rigid conduit to threaded rod, insulator support or mounting surface
• Standard & Approvals: cULus Listed, PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
• Catalog ID: SWI1-WBA
• Conduit Size: 3/4 in EMT/Rigid
• Conduit Size (In.): 0.75
