Simpson Strong-Tie U24R Standard U Hanger 16 ga

Product Description

The Simpson Strong-Tie U24R is a standard U hanger designed for flexible joist to header installation. This product supports versatile fastener selection with tested allowable loads. The air release technology adheres to ACI 351.1 R standards, offering an effective bearing area achieved through proper grouting procedures.

• Pours, pumps, or dry packs for flexible installation
• AC certified for effective load bearing
• Compatible with multiple fastener sizes

Product Highlights

Highly adaptable for various framing applications, the U hanger allows for straightforward installation and reliable support.

Product Information

Standard Information

• Brand: Simpson Strong-Tie
• MPN: U24R

Technical Specifications

• Gauge: 16
• Finish: G90 Galvanized
• Load Specifications: Uplift (160) 240 lb, Floor (100) 575 lb, Snow (115) 650 lb, Roof (125) 705 lb
• Fastener Size: (4) 0.162 x 3-1/2 in (Header), (2) 0.148 x 1-1/2 in (Joist)
• Nominal Product Depth: 0
