Siemens UAT417-XG Talon Meter Socket 200 A

SIEMENS
Brand: SIEMENS
SKU: UAT417-XG
Availability: In Stock

Ships same day if ordered by 12 pm

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$81.04
$81.04
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The SIEMENS UAT417-XG Talon meter socket is a 200A, 4-jaw, ringless socket designed for 1-position overhead/underground feed. Constructed with a 16-gauge painted steel NEMA 3R enclosure, it's suitable for residential applications. The socket supports 6 AWG to 350 KCMIL wire sizes and features a glass-filled polyester block. It is UL Listed and ANSI C12-7 compliant.

  • 200 Amp, 4 Jaw
  • Ringless cover type
  • Overhead/Underground Fed

Product Highlights

The SIEMENS UAT417-XG meter socket is a reliable choice for residential meter mounting, offering durability and compliance with industry standards.

Product Information

Standard Information

  • Brand: SIEMENS
  • Manufacturer Part Number: UAT417-XG
  • Country of Origin: MEX

Technical Specifications

  • Number of Jaws: 4
  • Service Type: Overhead/Underground
  • Circuit Configuration: 1-Phase 3-Wire
  • Voltage Rating: 600 VAC
  • Current Rating: 200 Ampere
  • Bypass Switch Type: No
  • Hub Type: RX Closing Plate
  • Knockouts: (6) (1 Inch-1-1/4 Inch-1-1/2 Inch-2 Inch-2-1/2 Inch), (1) (1/4 Inch-1/2 Inch-7/8 Inch), (1) (1/4 Inch-1/2 Inch-7/8 Inch) Concentric Knockout
  • Neutral Type: Quad Ground
  • Wire Size: 6 AWG to 350 kcmil
  • Enclosure: Steel
  • Enclosure Material: 16 Gauge Painted Steel
  • Approval: UL
  • Applicable Standard: ANSI C12-7
  • Application: Residential Applications
  • Block Material: Glass Filled Polyester
  • Feed Type: Overhead/Underground
  • Phase: 1
  • Terminal Type: Lug
  • Enclosure Type: NEMA 3R
  • Mounting Type: Surface
  • Type: 8-Cutout 1-Position Type UAT4
  • Manufacturer: Siemens
  • Brand: Siemens
