Description

Product Description

The Siemens SN351CR is a 3-position Type UAS8/9 low-voltage residential meter socket rated 100 A and 300 VAC. It provides a five-jaw terminal configuration for end or overhead feed and accepts 6 AWG to 250 kcmil on the line and 8 to 2/0 AWG on the load. The surface-mount unit features an RX closing plate hub, ring cover and a NEMA 3R enclosure with multiple cutouts for wiring.

  • Rated 100 A, 300 VAC; suitable for 1 or 3 phase residential metering (Type UAS8/9).
  • Five-jaw line/load lug terminals; accepts 6 AWG to 250 kcmil (line) and 8 to 2/0 AWG (load).
  • Surface mount NEMA 3R enclosure with RX closing plate hub, ring cover, and 13 cutouts for wiring flexibility.

Product Highlights

3-position UAS8/9 residential meter socket; 100 A, 300 VAC; surface mount; no bypass.

Product Information

Standard Information

  • Brand: SIEMENS
  • Manufacturer Part Number: SN351CR
  • Country of Origin: USA
Technical Specifications
Brand
Siemens
Manufacturer Part Number
SN351CR
Type
3-Position Type UAS8/9 Low Voltage Residential
Amperage Rating
100 A
Voltage Rating
300 VAC
Phase
1 or 3
Wire Size (Line)
6 AWG to 250 kcmil
Wire Size (Load)
8 to 2/0 AWG
Terminals
5 (line/load lug)
Jaws
5-jaw
Mounting Type
Surface
Enclosure Rating
NEMA 3R
Enclosure Material
G90 galvanized steel or 3003 grade aluminum
Hub Type
RX closing plate
Cover Type
Ring cover
Dimensions (H x W x D)
30.8 in x 17.2 in x 5.0 in
Cutouts
13 cutouts (2 x 2.750; 9 x various sizes 1 to 2; 2 x various sizes 1/2 to 1-1/2)
Cable Entry
End/Overhead (OH)
Bypass
No bypass
Application
Residential
Standards/Certifications
UL
Operating Temperature
Average ambient
Feature Notes
Stainless steel hardware, polyester powder coat finish; commercial sockets include plated copper current path
