Siemens 14BUB32AF Starter, FVNR SZ00, 0.7

Product Description

The Siemens 14BUB32AF is a non-reversing motor starter, size 00, designed for three-phase full voltage applications. It features a solid-state overload relay with an OLR amp range of 0.75-3.4A and a 110V 50Hz / 120V 60Hz coil. This non-combination type starter has an open enclosure.

• Non-reversing motor starter
• Solid-state overload relay
• Open enclosure type

Product Highlights

The Siemens 14BUB32AF motor starter is ideal for across the line starting of 1-phase and polyphase motors.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 14BUB32AF
• Country of Origin: Mexico

Technical Specifications

• Size: S00 in
• Type: Heavy Duty
• Voltage: Three phase full voltage
• Overload Relay: Solid-State
• OLR amp range: 0.75-3.4A
• Coil: 110V 50Hz / 120V 60Hz
• Combination Type: Non-combination type
• Enclosure Type: Open
• Enclosure: No enclosure
• Amperage: 9 Amp
• Motor Power: 2 hp
• Number of Phases: 3 Phase
• Number of Poles: 3 Pole
• Operating Cycles: 10000000
• Power Supply: 600 V
• Reset Type: Automatic/Manual/Remote
• Voltage Rating: 575 V
• Coil Voltage: 110/120
• Frequency Rating: 50/60
• Operating Temperature: -4 to 104
• Amperage Rating: 0.75 to 3.4
• Horsepower, Max, 3 Phase, at 200 V: 1\u20442
• Horsepower, Max, 3 Phase, at 230 V: 3\u20444
• Horsepower, Max, 3 Phase, at 460 V: 11\u20442
• Horsepower, Max, 3 Phase, at 575 V: 2
• Mounting Type: Panel Mount
• Phase: 3 Phase
• Primary Type: DOL Starter
• Series: FVNR Series
• Starter Type: NEMA Starter
• Auxiliary Contact Form: 1NO
• Auxiliary Contacts Included: 1NO
• Max. Voltage Rating: 600V AC
• Overload Protection Type: Electronic
• Reversing Capability: Non-Reversing
• Trip Class: 5/10/20/30
• Wire Termination Type: Screw
