Shurjoint SJT70414PE 4-inch Hinged Flange Adapter

Product Description

The Shurjoint SJT70414PE is a 4-inch hinged flange adapter designed for the connection of grooved systems to flanged systems. Its two-segment design simplifies installation. Made from ductile iron, it features a durable orange paint finish. The adapter includes an EPDM rubber gasket and plated track bolts and nuts. This product is applicable in various systems such as heating, cooling, compressed air, sprinklers, and fire main systems.

• Allows direct connection to an ASTM Class 150 flange.
• Small triangular teeth in the key shoulder prevent pipe rotation.
• Maximum operating pressure is 290.08 psi at twenty degrees Celsius.

Product Highlights

Designed for reliable connections in various piping applications, the Shurjoint SJT70414PE flange adapter enables strong and secure installations.

Product Information

Standard Information

• Brand: Shurjoint
• MPN: SJT70414PE

Technical Specifications

• Fitting/Connector Type: Flange Adapter
• Nominal Size: 4 inches
• Outer Pipe Diameter Connection 1: 4.5 inches
• Outer Pipe Diameter Connection 2: 9.02 inches
• Material: Ductile Iron
• End Style: Grooved
• Series: 7041
• Pressure Rating: 290.08 psi
• Temperature Rating: -29.2 to 230 degrees Fahrenheit
• Medium Temperature (continuous): -29.2°F to 230°F
• Connection 1: Ribbing groove (groove coupling)
• Connection 2: Flange
• Finish: Painted
• Color: Orange
• Length: 9.02 inches
• Length of Connection 1: 0.94 inches
• Material Sealing: Ethylene-propylene diene monomer rubber (EPDM)
• Certifications: cULus Listed, FM Approved, UL Listed, ULC Listed
