Securitron el-cept-630 Electrical Power Transfer

Product Description

The SECURITRON el-cept-630 is a concealed electrical power transfer device designed to carry low-voltage electrical signals across a door frame and door leaf without exposed wiring. It fits into the hinge side of the door assembly and provides a continuous electrical pathway for access control hardware such as electric strikes, magnetic locks, or door-mounted readers. The satin stainless steel finish (US32D) gives it a clean, professional appearance suited to commercial door hardware installations. Licensed locksmiths, access control technicians, and commercial door hardware installers are the primary trades that work with this device.

The el-cept-630 is intended for commercial hollow metal or wood door assemblies where concealed wiring is required between the door frame and the door itself. It is part of the Electrolynx product family, which provides a low-profile, hinge-mounted transfer point for low-voltage wiring. This makes it well suited for new construction and retrofit access control projects where visible conduit or loop wires are not acceptable by the specifying architect or end user.

Key Features

• Concealed installation keeps wiring hidden within the door and frame
• Satin stainless steel finish (US32D) for a clean, durable surface appearance
• Electrolynx design provides a continuous electrical pathway across the door pivot point
• Suited for low-voltage access control circuits including electric strikes and card readers
• Designed for commercial door hardware applications

Compatibility

Designed as a concealed OEM-style electrical power transfer for commercial door assemblies requiring low-voltage signal transfer across the door hinge line, consistent with the Electrolynx product family.

Installation Notes

Installation is performed by licensed locksmiths or access control technicians familiar with commercial door hardware. De-energize all low-voltage circuits connected to the door hardware before beginning installation. Routing and termination of conductors should comply with applicable local electrical codes and the access control system manufacturer wiring requirements. Do not exceed the rated voltage and current of the device as specified by the manufacturer documentation.

Technical Specifications

• Finish: Satin Stainless Steel (US32D)
• Mounting Type: Concealed
• Product Family: Electrolynx

Standard Information

• Brand: SECURITRON
• Manufacturer Part Number: el-cept-630
