Schneider Electric 9001KS46 Selector Switch 3 Position 600V

Product Description

The SCHNEIDER ELECTRIC 9001KS46 is a 3-position, maintained-action selector switch designed for panel-mount industrial control applications. It operates at up to 600 volts and features a push-button operator style with a chrome metal bezel. The switch ships without contact blocks, allowing the installer to configure the contact arrangement to match the control circuit requirements. Rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures, it is built for environments where dust resistance, oil resistance, and weatherproofing are required. Licensed electricians and industrial control panel builders are the typical installers.

This selector switch is suited for use in industrial and commercial control panels where a 3-position maintained switching function is needed. The 30 mm panel cutout is a widely used standard in industrial operator interface hardware, making this switch compatible with standard pushbutton station enclosures and control panel assemblies. Typical applications include motor control circuits, machine tool controls, and process equipment switching where a stable, latched position is required rather than a momentary action.

Key Features

• 3-position maintained action for stable, latched switching in control circuits
• 600-volt rating supports a wide range of industrial control voltage levels
• Chrome metal bezel provides durability and a standard industrial appearance
• 30 mm panel mount cutout fits standard industrial enclosure hole patterns
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings cover dust, oil, and weatherproof environments
• Ships without contact blocks, allowing custom contact block configuration by the installer
• CE, CSA LR24590 Class 3211 03, and UL Listed (File E42259 CCN NKCR) certifications

Compatibility

Designed as an OEM-style panel-mount selector switch operator for standard 30 mm industrial control panel cutouts. No specific compatible model numbers were provided in the product data.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the control panel before mounting or wiring this switch. The operator mounts through a 1.18-inch panel cutout and requires separately ordered contact blocks to complete the switching circuit. Verify enclosure NEMA rating matches the environmental conditions of the installation location before final assembly.
