Schneider Electric 2364-220 Pneumatic Electric Relay DPDT Setpoint Range

Product Description

The Schneider Electric 2364-220 is a pneumatic electric relay designed for applications that require the conversion of air pressure changes into electrical switching actions. It features a double-pole double-throw (DPDT) configuration and operates within a setpoint range of four to twenty pounds per square inch gauge (psig). This relay is commonly used for starting and stopping unit ventilators, fan coil motors, unit heaters, and air handling unit fans.

• DPDT configuration
• Setpoint range of 4 psig to 20 psig
• Used in various control systems

Product Highlights

Ideal for control systems, the Schneider Electric 2364-220 relay helps automate processes through precise pressure control.

Product Information

Standard Information

• Brand: Schneider Electric
• Part Number: 2364-220

Technical Specifications

• Configuration: DPDT
• Setpoint Range: 4 psig to 20 psig
• Application: Controls for unit ventilators and fans
• Diaphragm Type: Nonmetallic
