SATCO 65-571R1 2x2 LED Backlit Flat Panel with Selectable Wattage and CCT

Product Description

The SATCO 65-571R1 is a two by two LED backlit flat panel designed for indoor lighting applications. This panel features selectable wattage and CCT options, allowing for custom lighting configurations. It operates on a voltage range of one hundred to two hundred seventy-seven volts and supports 0-10V dimming. The construction includes aluminum, steel, and a PMMA lens suitable for various installation scenarios.

• Selectable wattage: twenty watts, thirty watts, or forty watts.
• Select from color temperatures: thirty-five hundred Kelvin, four thousand Kelvin, or five thousand Kelvin.
• Compatible with 0-10V dimming systems.

Product Highlights

This product is ideal for various settings, making it versatile and adaptable for different lighting needs.

Product Information

Standard Information

• Brand: SATCO
• MPN: 65-571R1

Technical Specifications

• Technology: LED
• Panel Size: 2x2
• Input Voltage: 100-277V
• Wattage: 20W/30W/40W
• Lumen Output: 2200L-4600L
• Color Temperature: 3500K/4000K/5000K
• Color Rendering Index: 80+
• Beam Angle: 120 degrees
• Rated Life Hours: 50000
• Operating Temperature: -17 degrees Celsius to +45 degrees Celsius
• Dimmable: Yes, 0-10V dimming
• Lens Material: PMMA
• Construction Material: Aluminum/Steel
• IP Rating: IP20
• Location Rating: Damp
• Certifications: IP20, DLC, ETL, RoHS, cETLus - Listed
• Length: 23.75 inches
• Width: 23.75 inches
• Height: 1.5 inches
• Weight: 4.85 lb
• Power Factor: 0.9
• Total Harmonic Distortion: 0.09
• Lens: Frosted
• Efficacy: 110 - 115 lm/W
• Surge Protection: Built-in surge protection - 2KV
• Finish: White
• Driver: Internal
• UL Application: LED Panel Luminaire
• RoHS Compliant: Yes
• FCC Compliant: Yes
• Canadian Standard ICES-005: Class A
• Flicker Free: Yes
• Warranty: 5 Years
