ROBERTSHAW K305 Uni-Line Cold Control

Product Description

The Robertshaw K305 is a Uni-Line cold control that serves as a direct replacement in the 3030-100 series. This control is engineered to match original equipment manufacturer (OEM) specifications for temperature regulation, dial shaft, capillary length, and mounting, making installation quick and simple. As part of the Robertshaw K Series electric thermostats, this cold control is a snap-acting, single-pole single-throw (SPST) device. It has a current rating of twenty-five amps, constructed with silver contacts and heavy-duty terminals ensuring reliability and durability.

• Direct replacement control matching OEM specifications for temperature, dial shaft, capillary length, and mounting.
• Snap-acting, single-pole single-throw (SPST) switch for precise temperature management.
• UL and CSA listed, meeting recognized safety and performance standards.

Product Highlights

This reliable cold control is suitable for a variety of applications in need of accurate temperature control, especially in the commercial cooking industry.

Product Information

Standard Information

• Temperature Control Type: Cold Control / Electric Thermostat
• Switch Type: Single Pole Single Throw (SPST)

Technical Specifications

• Current Rating: 25 Amp
• Agency Certifications: CSA, UL, AGA, CE available
• Ambient Temperature Range: 32°F to 200°F (0°C to 93°C)
• K Series Temperature Ranges: Up to 975°F (524°C) with NAK filled diastats
• Bulb and Capillary Material Options: Copper, nickel plated copper, stainless steel
• Available Bulb Diameters: 0.187 inches (4.8 mm), 0.250 inches (6.4 mm), 0.312 inches (7.9 mm), 0.375 inches (9.5 mm)
