Robertshaw 829-003 Direct Spark Ignition Control

Product Description

The Robertshaw 829-003 is a direct spark ignition control suitable for 35-60 series, 24-volt direct spark ignition systems. This unit features a microprocessor to manage the gas burner operation efficiently. It provides a ten-second ignition trial and allows for a single ignition attempt prior to lockout. The incorporation of remote flame sensing and an auto-reset function enhances safety and reliability.

• Compatible with 35-60 series, 24-volt systems.
• Includes remote flame sensing and auto-reset capabilities.
• Edge connector for easy installation.

Product Highlights

The control unit is built with gray Noryl, ensuring durability. It operates within a voltage range of eighteen to thirty volts AC at fifty or sixty hertz frequency. The gas valve is rated at two amps at twenty-four volts AC.

Product Information

Standard Information

• Series Application: 35-60 Series, 24 Volt Direct Spark Ignition
• Construction: Gray Noryl

Technical Specifications

• Flame Sensor Method: Remote
• Trial for Ignition: 10 seconds
• Ignition Attempts Before Lockout: 1
• Gas Valve Rating: 2.0 Amps @ 24V AC
• Control Voltage: 18-30V AC 50/60 Hz
• Electrical Rating: 24V AC 300 mA
• Connection Type: Edge Connector
• Auto Reset: Yes
