ROBERTSHAW 8141-0 Refrigerator Defrost Timer

Product Description

The ROBERTSHAW 8141-0 is a refrigerator defrost timer designed for heat, hot gas, or compressor shutdown applications. It operates at one hundred twenty volts AC at fifty to sixty hertz. Rated for forty amps and a power of two horsepower, this timer offers defrost frequency adjustments from one to six cycles per day.

• Features a 1NO-2NC switch type for reliable operation.
• Allows defrost frequency adjustment from one to six cycles daily.
• Constructed in a durable steel enclosure with security features.

Product Highlights

The unit supports both time and temperature initiation with adjustable back-up defrost termination from four to one hundred ten minutes. It has been approved by UL for use in Canada and the United States, adhering to ISO 9001 standards.

Product Information

Standard Information

• Brand: ROBERTSHAW
• MPN: 8141-0

Technical Specifications

• Switch Type: 1NO-2NC
• Current Rating: 40 Amp
• Voltage Rating: 120 Volt AC at 50/60 Hertz
• Power Rating: 2 HP
• Reserve Power: 1 to 6 Cycle per Day
• Material: Heavy Duty Steel (Enclosure)
• Application: Heat, Hot Gas or Compressor Shutdown
• Approval: UL (Canada and US)
• Switch Rating: 690 Volt Amp at 120 to 240 Volt AC
• Initiation/Termination Type: Time/Temperature/Pressure
• Includes Bracket: True
• Applicable Standard: ISO 9001
