Resideo V8043B1027 3/4 Sweat Connection Zone Valve 24V Replacement MPN

Product Description

The Resideo V8043B1027 is a 3/4 sweat connection zone valve designed for low voltage applications. This valve is ideal for controlling the flow of hot water in hydronic heating systems. It features a normally open position and operates at 24 volts.

• Two-way on-off control.
• Compact and easy to install without disassembly.
• Compatible with fresh water systems without dissolved oxygen.

Product Highlights

This low voltage motorized zone valve acts as an actuator and valve assembly, ensuring effective hydronic control. It's capable of withstanding fluid temperatures up to 200 degrees Fahrenheit and operates with a nominal timing of 15 seconds.

Product Information

Standard Information

• Manufacturer: Resideo
• MPN: V8043B1027

Technical Specifications

• Connection Type: Sweat
• Pipe Size: 3/4 inches
• Body Pattern: Two-way, Straight-through
• Fluid Temperature Range: 40°F - 200°F
• Power Consumption: 7.7 VA
• Maximum Close-off Pressure: 20 psi
• Maximum Ambient Temperature: 125°F
• Dimensions: 4 inches height x 3.5 inches width x 2.375 inches depth
