REGAL REXNORD D977 PERMANENT SPLIT CAPACITOR MOTOR

Product Description

The Regal Rexnord D977 is a permanent split capacitor motor, ideal for various HVAC applications. It operates at two hundred seventy-seven volts and fifty to sixty hertz. This motor features three selectable speeds: one-third horsepower, one-fourth horsepower, and one-sixth horsepower, allowing for versatility in power output. The current draw is two point two amps for one-third horsepower, one point five amps for one-fourth horsepower, and zero point nine amps for one-sixth horsepower. The motor maintains a rotational speed of one thousand seventy-five RPM.

• Operates at 277V and 60 Hz.
• Provides three speed options: 1/3 HP, 1/4 HP, and 1/6 HP.
• Rotational speed of 1075 RPM.

Product Highlights

This motor is suitable for systems that require adjustable speed and power output.

Product Information

Standard Information

• Part #: D977
• Category: Motors/GearBox/Clutch
• Subcategory: Motor

Technical Specifications

• Horsepower Ratings: 1/3, 1/4, 1/6 HP
• Current Draw: 2.2 A, 1.5 A, 0.9 A
• Voltage: 277 V
• Frequency: 60 Hz
• Rotational Speed: 1075 RPM
• Weight: 4.99 kg
