Robertshaw O10-1410 Temperature Control 25-75F with 72 Inch Remote Bulb

Product Description

The Robertshaw O10-1410 temperature control is engineered for reliable and precise temperature management in industrial and commercial applications. This device operates within a temperature range of 25 to 75 degrees Fahrenheit, ensuring optimal performance for various processes.

• Adjustable temperature range from 25 to 75 degrees Fahrenheit
• 72-inch remote bulb for remote sensing in confined spaces
• Energy-efficient and durable construction

Product Highlights

This temperature control is ideal for use in industrial ovens, process heaters, and cooling systems. Its design includes a 72-inch capillary with a bulb sensor, allowing for accurate temperature monitoring in hard-to-reach areas. The robust construction includes a zinc-plated, pressed-steel casing with a laser-welded bellows for extended life. The control also features a NEMA 1 non-conductive, non-corrosive cover with a captive screw for easy access.

Product Information

Standard Information

• Application: Suitable for line or pilot duty cycling of motors, compressors, or solenoid valves
• Agency Compliance: UL Listed

Technical Specifications

• Control Range: 25-75 degrees Fahrenheit
• Temp Differential High: 3-20 degrees Fahrenheit
• Temp Differential Low: 6-25 degrees Fahrenheit
• Capillary Length: 72 inches
• Voltage: 120V
• Locked Rotor Amps: 144
• Full Load Amps: 24
• Pilot Duty Contacts: 720 VA
• Height: 2.75 inches
• Width: 3.5 inches
• Depth: 2 inches
• Bulb Diameter: 3/8 inch
• Bulb Length: 1-3/8 inches
• Construction: Zinc-plated pressed steel
• Includes: Dual temperature scale, mounting bracket, mounting screws, terminal screws, adjustment knob
