Sporlan PSK231N7EXBS Temp Control Digital for HVAC Refrigeration Controller 230 VAC

Product Description

The Sporlan PSK231N7EXBS is a high-performance digital temperature controller designed specifically for medium-temperature refrigeration systems. This unit provides effective management of refrigeration units by controlling compressors up to two horsepower.

• Digital output with a 30A compressor relay.
• Integrated buzzer for alarms and TTL serial communication port (RS485 Modbus).
• Compatible with NTC/PTC temperature sensors and has one multifunction input.

Product Highlights

Equipped with a 3-1/2 digit display, the Sporlan PSK231N7EXBS offers precise temperature readings and is suitable for both open and closed refrigeration systems. Its front panel is IP65 rated, ensuring protection against environmental factors. The multifunction input can be utilized for various applications including a door switch, evaporator temperature sensor for defrost termination, a condenser temperature sensor for overheat alarms, or an energy-saving mode trigger..

Product Information

Standard Information

• Brand: Sporlan
• MPN: PSK231N7EXBS

Technical Specifications

• Power Supply: N5 (120VAC, 50/60 Hz), N7 (230VAC, 50/60 Hz)
• Control Features: Temperature alarms, easy setup with optional programming key
• Physical Dimensions: Front bezel size 2.95 inches x 1.3 inches; Panel cut out 2.79 inches x 1.14 inches
• Weight: 1.5 lbs
