PARKER 404550 Electric Linear Actuator

Product Description

The PARKER 404550 is an electric linear actuator from the XR Series. It features a robust ball screw drive train and square rail guidance. This actuator is engineered for integration with servo motors and provides a stroke length of five hundred fifty millimeters. It achieves a peak speed of three hundred millimeters per second and supports a normal load capacity of one hundred seventy kilograms with a repeatability of plus or minus three microns.

• Stroke length of five hundred fifty millimeters
• Integrated with a five millimeter ball screw
• Capable of supporting a normal load of one hundred seventy kilograms

Product Highlights

This actuator is suitable for various applications requiring precise motion control, benefiting from its high speed and load capacity.

Product Information

Standard Information

• Brand: PARKER
• Manufacturer Part Number: 404550

Technical Specifications

• Product Type: Electric Linear Actuators
• Product Family: XR Series
• Drive Train: Ball Screw
• Form Factor: Rodless
• Motor: Servo
• Stroke: 550 mm
• Feed Constant: 5 mm Ball Screw
• Peak Speed: 300 mm/s
• Normal Load: 170 kg
• Repeatability: +/-3 micron
• Axial Force: 880 N
• Customizability: High
• Brand/Division: Electromechanical
• Product Category: Actuators
