Norton 076607-88270 Type 1 Bench Pedestal Grinding Wheel

Product Description

The NORTON 076607-88270 is a Type 1 straight bench and pedestal grinding wheel designed for general-purpose metal grinding and stock removal. Built from aluminum oxide abrasive, this wheel measures 7 inches in diameter, 1 inch wide, and has a 1-inch arbor bore. The medium grit rating makes it well-suited for general sharpening, deburring, and surface conditioning on ferrous metals. It is rated for a maximum operating speed of 3,600 RPM. Licensed trades including machinists, maintenance technicians, and metalworking shops rely on this wheel for everyday bench grinder use.

This wheel is intended for use on standard bench and pedestal grinders in industrial, commercial, and trade shop settings. The aluminum oxide construction handles carbon steel, alloy steel, and other ferrous materials effectively. It is well-matched to maintenance and repair operations where consistent, controlled material removal is required. Each unit is sold individually, with a minimum order quantity of 5 units per order.

Key Features

• Type 1 straight profile for use on bench and pedestal grinders
• General-purpose aluminum oxide abrasive for ferrous metal grinding
• Medium grit for balanced stock removal and surface finish
• 7-inch diameter with 1-inch wide face and 1-inch arbor bore
• Rated to 3,600 RPM maximum operating speed

Compatibility

Designed as a general-purpose replacement or service wheel for standard bench and pedestal grinders accepting a 7-inch diameter, 1-inch wide, 1-inch bore Type 1 wheel.

Installation Notes

Grinding wheel mounting should be performed by a qualified technician following ANSI B7.1 safety standards for the use, care, and protection of abrasive wheels. Always power down and lock out the grinder before removing or installing a wheel. Inspect the wheel for cracks or chips before mounting, and perform a ring test per ANSI guidelines. Do not exceed the 3,600 RPM maximum speed rating stamped on the wheel.

Technical Specifications

• Wheel Type: Type 1 (Straight)
• Abrasive Material: Aluminum Oxide
• Grit Grade: Medium
• Diameter: 7 inches
• Width: 1 inch
• Arbor Bore: 1 inch
• Maximum RPM: 3,600
• Color: Gray
• Unit of Measure: Each
• Minimum Order Quantity: 5

Standard Information

• Brand: NORTON
• Manufacturer Part Number: 076607-88270
