NIBCO 81405HV Isolator Uni-Flange Ball Valve

Product Description

The NIBCO 81405HV is an Isolator uni-flange ball valve designed for use with water in various applications. This valve is suitable for residential, commercial, or industrial use. It features a forged brass body and provides a full port design. Key components include PTFE softgoods, a detachable rotating flange, and an adjustable packing gland with accompanying nuts and bolts.

• Designed for high velocity or standard circulators.
• Features a press connection type and rotating flange for installation.
• Adjustable packing nut for easy maintenance.

Product Highlights

This valve ensures reliable flow control and connection with water systems while being easy to install and maintain.

Product Information

Standard Information

• Brand: NIBCO
• MPN: 81405HV

Technical Specifications

• Series: 8140
• Nominal Size: 1-1/4 inches
• Connection Type: Press x Rotating Flange
• Port Type: Full
• Body Material: Forged Brass
• Ball Material: Chrome Plated Brass
• Softgoods Material: PTFE
• Pressure Rating: 250 psi
• Temperature Rating: 250 degF
• Media: Water
• Inlet to Outlet Length: 4-7/16 inches
• Top to Inlet Center: 2-15/16 inches
• Height: 3.54 inches
• Length: 2.0 inches
• Width: 4.44 inches
• Weight: 2.05 pounds
• Non-Potable: Yes
• Drain: No
• Domestic/Import: Import
