Multiple 719024623 MWC A30008PB 18/2 Unshielded Stranded Plenum White 1000 FT Pull Box

Product Description

Multiple 719024623 MWC A30008PB is an unshielded electronic plenum cable designed for various applications. This cable features two conductors, each sized 18 AWG stranded and made from bare copper. The insulation and jacket are composed of low smoke PVC, ensuring safety and compliance with standards.

• Type CMP/CL3P (UL), CMP/FT6 (CUL) rated.
• Voltage rating up to 300 V.
• Ideal for audio systems, communication, and security applications.

Product Highlights

This cable is suitable for use in sound systems and remote control applications, providing reliability and efficiency in various settings.

Product Information

Standard Information

• Brand: Multiple
• Part Number: 25754

Technical Specifications

• Conductor Size: 18 AWG
• Number of Conductors: 2
• Voltage Rating: 300 V
• Insulation Material: Low Smoke PVC
• Jacket Material: Low Smoke PVC
• Outer Diameter: 0.142 inches
• Length: 1000 FT
• Temperature Rating: -20 to 75 Deg C
• Applications: Audio/Sound System, Communication, Nurse Call, Remote Control, Security System, Signaling, Single Line Telephone
• Approval: UL 13, UL 444, CUL
• Applicable Standard: NEC 725/800
