Micrometl 9901-2499 Actuator 6 Volt Amp

Product Description

The MicroMetl 9901-2499 Actuator is a direct-coupled, spring return damper actuator designed for HVAC systems. It operates on 24 VAC/VDC and 120 VAC, 50/60 Hz, with a power rating of 6 VA driving and 3 VA holding. The actuator features a die-cast aluminum construction and provides 44 inch-pound of torque with an adjustable rotation angle from 0 to 95 degrees.

• Volume Control Dampers, Mounted Directly to the Drive Shaft or Remotely (With the Use of Accessory Hardware)
• Quarter-Turn Rotary Valves, Such as Ball or Butterfly Valves Mounted Directly to the Drive Shaft
• Linear Stroke Globe or Cage Valves Mounted with Linkages to Provide Linear Actuation

Product Highlights

This actuator is ideal for use in heating, ventilating, and air-conditioning (HVAC) systems. It is suitable for NEMA 2, IP54 environments and is approved by IEC, C-Tick, UL, and CE standards.

Product Information

Standard Information

• Brand: MICROMETL
• Manufacturer Part Number: 9901-2499

Technical Specifications

• Type: Direct-Coupled
• Operation Type: Spring Return
• Maximum DC Voltage: 24 Volt
• Frequency Rating: 50/60 Hertz
• Power Rating: 6 Volt Amp (Driving), 3 Volt Amp (Holding)
• Torque: 44 Inch-Pound
• Angle of Rotation: 0 to 95 Degree
• Enclosure: NEMA 2, IP54
• Size: 6.968 Inch Length x 3.859 Inch Width x 3.156 Inch Height
• Shaft Diameter: 0.375 to 0.625 Inch
• Body Material: Plenum Rated Plastic
• Operating Temperature: -40 to 150 Deg F
• Application: Heating, Ventilating and Air-Conditioning (HVAC) System
• Approval: IEC 60730-1, C-Tick N314, UL 873/1097, CE
• Drive Time: 90 Second
• Feedback Signal: 2 to 10 Volt DC, 3 Milliamp
• Shaft Information: 0.25 to 0.5 Inch Square
• Electrical Connection Type: 18 to 14 AWG Conductor (Solid), 2 to 14 AWG Conductor (Stranded)
• Operating Humidity: 5 to 95 Percent (Non-Condensing)
