Magnaloy Coupling Co. M056352AA Horizontal Pump/Motor Mount Adapter

Product Description

The Magnaloy Coupling Co. M056352AA is designed for mounting horizontal pumps and motors. This adapter is constructed from aluminum and compatible with SAE AA pump flanges.

• Durable aluminum construction
• Compatible with multiple motor frames
• Designed for horizontal and vertical mounting

Product Highlights

This mount adapter supports a variety of motor frames, including 56C and 143TC/145TC. It's suitable for both horizontal and vertical installations, making it versatile for different applications.

Product Information

Standard Information

• Brand: Magnaloy Coupling Co.
• Part Number: 100439551

Technical Specifications

• Mounting Type: Horizontal, Vertical
• Material: Aluminum
• Motor Mount Holes: 4
• Radial Clearance: 4.15 inches
• Pump/Motor Mount Length: 3.5 inches
• Axial Clearance: 2.81 inches
• Pump Flange: SAE AA
• Motor Frame Compatibility: 56C, 143TC/145TC, 182UC/184UC
• Pump Flange Type: SAE
• Weight: 3.0 pounds
